JAX-WS: WS client generating with SoapUI

Sep 02, 10 by Juan Lebrijo about SoapUI, Web Services, Java, blog

We will create the needed classes to generate a Web Service client from its WSDL. We will base in the HelloWorld project, and here will add the security. In this project we response with a Hello for the name which sent as argument through the Web Service. In order to generate the classe we will use SoapUI:

We must to locate in our hard disk the wsimport.bat tool, downloaded with the SUN standard package implementation (of JAX-WS):

It generates a folder with sources and other with compiled classes:

To write the client helped with this classes is as easy as this:

package client;

import java.net.MalformedURLException;
import java.net.URL;

import javax.xml.namespace.QName;
import javax.xml.ws.BindingProvider;

public class HelloClient {

    public static void main(String[] args) {
        HelloService service = null;
        try {
            // Creamos el servicio con el WSDL
            URL wsdlLocation = new URL("http://localhost:7001/wsc/HelloService?WSDL");
            String targetNamespace="http://services/";
            String name="HelloService";
            service = new HelloService( wsdlLocation, new QName(targetNamespace, name));
            Hello port = service.getHelloPort();
            // Añadimos capacidades de seguridad a la llamada
            BindingProvider provider = (BindingProvider) port;
            provider.getRequestContext().put(BindingProvider.USERNAME_PROPERTY, "user");
            provider.getRequestContext().put(BindingProvider.PASSWORD_PROPERTY, "12345678");
            //Mostramos el resultado
            System.out.println(port.sayHello(args[0]));
        } catch (MalformedURLException e ) {
            e.printStackTrace();
        }
    }
}

JAX-WS Handler Chain: Interceptando los mensajes

Aug 29, 10 by Juan Lebrijo about Web Services, Java, blog

Queremos interceptar el WS en la salida y la entrada. Esto puede ser útil para:

Hacer log de alguna parte del mensaje
Llevar registro de mensajes enviados
Controles de seguridad añadidos
....

Hoy vamos a hacer un ejemplo de log de la entrada/salida del WS. Anotamos el WS con el descriptor de la cadena de manejadores:

@WebService
@HandlerChain(file="src/META-INF/handlerChain.xml")
public class Hello {
@WebMethod
    public String sayHello(String name) {
        return "Hello, "+name+".";
    }
}

Que tendrá el contenido siguiente:




         lebrijo.handlers.WSHandler

La clase WSHandler implementará la interfaz SOAPHandler:

public class WSHandler implements SOAPHandler {

     public Set getHeaders() {
         return null;
     }

     public boolean handleFault(SOAPMessageContext context) {
         logToSystemOut(context);
         return true;
     }

     public boolean handleMessage(SOAPMessageContext context) {
         logToSystemOut(context);
         return true;
     }

     private void logToSystemOut(SOAPMessageContext smc) {
         Boolean outboundProperty = (Boolean) smc.get(MessageContext.MESSAGE_OUTBOUND_PROPERTY);

         if (outboundProperty.booleanValue()) {
             System.out.println("\nOutgoing message:");
         } else {
             System.out.println("\nIncoming message:");
         }

         SOAPMessage message = smc.getMessage();
         try {
             message.writeTo(System.out);
         } catch (Exception e) {
             System.out.println("Exception in handler: " + e);
         }
     }

	public void close(MessageContext context) {
		// TODO Auto-generated method stub

	}

JAX-WS Handler Chain: messages interceptor

Aug 29, 10 by Juan Lebrijo about Web Services, Java, blog

We want to intercept the WS input and output. In order to:

Logging any part in the message
Registering sent messages
Add security controls
....

Here we are going to do a input/output WS example log. We annotate the WS with Handler Chain descriptor:

@WebService
@HandlerChain(file="src/META-INF/handlerChain.xml")
public class Hello {
@WebMethod
    public String sayHello(String name) {
        return "Hello, "+name+".";
    }
}

It will have the following contents:




         lebrijo.handlers.WSHandler

WSHandler class will implements the SOAPHandler interface:

public class WSHandler implements SOAPHandler {

     public Set getHeaders() {
         return null;
     }

     public boolean handleFault(SOAPMessageContext context) {
         logToSystemOut(context);
         return true;
     }

     public boolean handleMessage(SOAPMessageContext context) {
         logToSystemOut(context);
         return true;
     }

     private void logToSystemOut(SOAPMessageContext smc) {
         Boolean outboundProperty = (Boolean) smc.get(MessageContext.MESSAGE_OUTBOUND_PROPERTY);

         if (outboundProperty.booleanValue()) {
             System.out.println("Outgoing message:");
         } else {
             System.out.println("Incoming message:");
         }

         SOAPMessage message = smc.getMessage();
         try {
             message.writeTo(System.out);
         } catch (Exception e) {
             System.out.println("Exception in handler: " + e);
         }
     }

	public void close(MessageContext context) {
		// TODO Auto-generated method stub

	}
